QDY8 Series Servo Valve

Description
QDY8 throttle control servo valve is a key control part of the electro-hydraulic servo control system, acting on electro-hydraulic conversion and power amplification, which performance and reliability will directly affect the performance and reliability of the entire system.
To be specific, it can receive the electrical signal passed by system directly, and convert it into a load flow or pressure signal which is polarized, proportional and can control the electro-hydraulic servo valve, so that the system will output hydraulic power to drive the corresponding executive bodies.

Application
Our self-developed electro hydraulic servo valves have been widely used in metallurgy, aerospace, shipbuilding, automobile, textile and printing industry.

Features of QDY8 Throttle Control Servo Valve
1. The machine uses a double-nozzle flapper valve as the pilot level, and furnished with electric feedback for main valve core position.
2. With good dynamic behavior and low energy consumption, it meet requirements for valves with high frequency response and flow from industrial fields.
3. Adopting an external controlling amplifier, which is easy to adjust.
4. Allowing users selecting external controlling and discharging way for pilot controlling oil.

Technical Parameters of QDY8 Throttle Control Servo Valve

Type of electro hydraulic servo valve			QDY8
Supply oil pressure range		Mpa	2 to 14
Rated supply oil pressure		Mpa	14
Rated flow QN [L/min] (at valve pressure drop of 7MPa)		L/min	10, 30
Rated current		mA	10
Hysteresis		%	≤3
Resolution		%	≤0.5
Non linearity		%	≤±8
Asymmetry		%	≤±10
Pressure gain		%	＞30
Internal leakage		L/min	≤1.1
Bias		%	≤±3
Zero drift of supply oil pressure(80 to 110% Ps)		%	≤±2
Zero drift of return oil pressure(0 to 20% Ps)		%	≤±2
Zero drift in temperature(-30 to +150)		%	≤±4
Frequency	Amplitude frequency width (-3db)	Hz	≥30
	Phase frequency width (-90°)	Hz	≥35
Work temperature		℃	-30 to +100
Net weight		Kg	1.4
